Camera, USB2.0, CCD, 0,8MP
0 Reviews | Review toevoegen

 CCD, 0,8MPixel Windows/Linux/OSX multiple platform SDK zinc aluminum alloy housing

Artikelnummer

766700800A

€ 500,00
excl. btw
€ 605,00
incl. btw
Prijs per



Aantal:
Bestellen
Op verlanglijst


| Meer

Heeft u een vraag over dit product?

Stel ons uw vraag



UHCCD: BMS UHCCD is an ultra-high performance HAD CCD camera. The camera adopts Sony Super HAD CCD sensor as the image-picking device; The Super HAD CCD is a version of Sony's high performance CCD HAD (Hole-Accumulation Diode) sensor with sharply improved sensitivity by the incorporation of a new semiconductor technology developed by Sony Corporation. USB2.0 is used as the data transfer interface.



UHCCD comes with advanced video & image processing application BMS_pix3; Providing Windows/Linux/OSX multiple platform SDK; Native C/C, C#/VB.NET, DirectShow, Twain Control API;



The UHCCD can be widely used in brightfield light environment and microscope image capture and anaysis.


  Sensor & Size(mm) Pixel(?m) G Sensitivity
Dark Signal
FPS/Resolution Binning Exposure







ICX204AK(C)



1/3" (4.76x3.57)



4.65x4.65



400 mv with 1/30 s
16 mv with 1/30 s



16@1024x768



1x1



0.16 ms~60 s


OTHER HARDWARE CONFIGURATION

Spectral Range

380-650 nm (with IR-filter)

White Balance

ROI White Balance/ Manual Temp-Tint Adjustment

Color Rendering Technique

Ultra Fine Color Engine

Capture/Control API

Native C/C, C#/VB.NET, Directshow, Twain, Labview

Recording System

Still Picture and Movie

Cooling System*

Natural

OPERATING ENVIRONMENT

Operating Temperature

-10 ~ 50 °C

Storage Temperature

-20 ~ 60 °C

Operating Humidity

30 ~ 80% RH

Storage Humidity

10 ~ 60% RH

Power Supply

DC 5V over PC USB Port

BMS_pix3 SOFTWARE ENVIRONMENT

Operating System

Support Microsoft Windows 7/8/10 (32 & 64 bit)
OS X (Mac OS X), Linux

PC Requirements

CPU: Equal to Intel Core2 2.8 GHz or Higher

Memory: 2 GB or More

USB port: USB2.0 High-speed Port

Display: 17" or Larger

CD-ROM



UHCCD Series C-mount USB2.0 CCD Camera Dimension

Installation drawings(Click to enlarge). The UHCCD Series USB2.0 CCD camerabody, made from tough, zinc alloy, ensures a heavy duty, workhorse solution. The camera is designed with a high quality IR-CUT to protect the camera sensor. No moving parts included. This design ensures a rugged, robust solution with an increased lifespan when compared to other industrial camera solutions.
